According to the model of the HPHT cubic press selected by the customer, it is an important part of our Turn-key project to carry out layout design and supporting project design for the customer. The following is based on the project of 50 sets QMYG850 cubic presses.

According to the actual demand, if the customer conducts industrial diamond production, customer needs to have a synthetic site and a post-processing site. The synthesissite is a standard factory building with a height of21m×140m and a lifting height of more than 8m. The factory building has two lifting equipment with specifications above 16 tons. A set of cooling circulating water system, and the workshop foundation should also be constructed according to the standard, a pickling site of about 45 ㎡ should be built, with a lifting device of more than 5 tons.If customers have requirements for environmental protection, an air and water treatment system should be added. The electricity requirement is to have a transformer with a power of more than 1600KVA.

Figure 1 Layout of QMYG850(50 sets) HPHT cubic presses

Figure 2QMYG850 base diagram

Figure 3Layout of post-processing and exhaust gas treatment equipment

The flow chart of industrial diamond synthesisand post-processingis as follows
